KO TECHNOLOGIES- CUSTOM DRIVE TRAIN AND BRUSHLESS MOTOR DESIGN.
INDUSTRY LEADING FIRST PERSON VIEW MOTORS
Our FPV motors boast a whole range of technical achievements and industry firsts
UNIQUE BASE PLATE
CRYO STATOR
OPEN CAGE BEARINGS
The Method XS comes with a every uniquely designed base plate that allows you to fill the oil sump with Race Oil X to lubricate the bearings.
All of our method series motors come fully equipped with a CRYO tech capable stator. To find out more about CRYO click here.
Using the best quality open cage bearings from EZO allows us to reduce friction and therefore heat in all of our Method motors. Giving a super smooth flight and cool running temps.
CRYO TECHNOLOGY - RACE OIL X - ACPC - OPEN CAGE BEARINGS - WET SUMP
The Method R 2207.5 Motor available in various KV.
Designed from scratch to be the ultimate race motor, unmatched power and torque with ultra smooth operation.
4025
Available in 440KV and 900KV
MOTOR WEIGHT
304g with wires.
(extension wires also supplied in the box)
HAND WOUND
10 Pole hand wound stator maximising the amount of copper used.
KO MOTORS UNIQUE DESIGN QUEUES
Unique design and styling that is unmatched in the FPV industry
BUILT IN ORGA PUMP TO DRAW OIL INTO THE BEARING AIDING COOLING AND EFFICIENCY.
30MM DIAGONAL M4 BOLT PATTERN FOR EASY FITTING TO MANY XCLASS SIZED FRAMES
CNC ANTI PROP
SLIP DESIGN.
SUMP PLUG FOR EASY ACCESS TO THE BEARINGS AND OIL CHANGES.
SINGLE STRAND HAND WOUND STATOR WITH THE HIGHEST QUALITY WINDINGS.
ACTIVE CHOKE POINT TECHNOLOGY (PATENTED) TO IMPROVE COOLING ON THE STATOR DURING FLIGHT.
UNIQUE CRYO STATOR COATING (PATENTED) MAKING THE STATOR RESISTANT TO EXTREME CHANGES OF TEMPERATURE.
N52SH HIGH QUALITY
MAGNETS.
7075 ALUMINIUM HIGH
QUALITY BASE DESIGN.
UNIQUE OPEN CAGE
BEARING DESIGN TO
BE USED WITH OIL FOR
MUCH IMPROVED COOLING
KO UNIQUE TITANIUM SHAFT DESIGN
MAGNET
N52SH MAGNETS
BEARING
EZO 19 X 8
STATOR LAMINATE
0.15 NIKKON JAPANESE STEEL
SHAFT
HOLLOW TITANIUM
WEIGHT
304G
WIRE LENGHTH
400MM
VOLTAGE
12S
Please email ben@ko-technologies.com for more information regarding this motor.
WIRE AWG
14 AWG
BELL MATERIAL
7075 ALUMINIUM
BASE MATERIAL
7075 ALUMINIUM
WIND INFO
220 DEGREE 99.9% PURE COPPER, 10 POLE 2Y.
COOLING
ACTIVE CHOKE POINT COMPRESSION
WINDING QC
TEST TO 500VOLT @ LOW AMPS
BALANCE
QC
DUAL STAGE DYNAMIC TEST FOR EACH BELL
Each Method motor has a built in chamber "wet sump" precisely engineered to hold a small amount of RACEX OIL. This feeds into the open case bearings via the patented KO orga main shaft.
​
While we use the very best EZO bearings possible there is still room for improvement and efficiency. This is achieved by adding a thin layer of RACEX OIL delivered by the orga pump. This gives the bearings a higher degree of tolerance for a highly balanced motor.
​
​
See more
Each Method motor has a built in chamber "wet sump" precisely engineered to hold a small amount of RACEX OIL. This feeds into the open case bearings via the patented KO orga main shaft.
​
While we use the very best EZO bearings possible there is still room for improvement and efficiency. This is achieved by adding a thin layer of RACEX OIL delivered by the orga pump. This gives the bearings a higher degree of tolerance for a highly balanced motor.
​
​
See more
REMOVABLE BASE PLATE
With integrated wet sump and machined orga pump which draws oil into the bearings. This reduces friction and helps to dissipate heat.
see more
OPEN CAGE BEARINGS
Our Method range of motors all use open bearings. This dramatically reduces friction and helps prevent heat soak.
see more
ACTIVE CHOKE POINT
KO Technologies has developed ACPC to compress oncoming air directly at the bell spoke face, forcing the air past the spokes and directly into the stator and magnet assembly..
see more
CRYO TECHNOLOGY
Our Method range of motors all use open bearings. This dramatically reduces friction and helps prevent heat soak.
